Quick Details
Type:
LED Triproof light
Certification:
CE,CB,RoHS,GS,SAA,etc.
Model Number:
EA15, EA15-15W-630 - EA15-50W-1530
Size:
600x70x68mm - 1500x70x68mm
IP Rating:
IP65
Work Lifetime:
5 Years
Operating temp range.:
-15°C+35°C
Environment:
-25℃--- +60℃
CRI:
>80
Beam Angel(°):
120
Operating Humidity(°C):
10%-90%
Lamp Power:
15/20/24/30/36/50W
Supply Ability
Supply Ability:
.JPG)
|
Model No. |
EA15-15W-630 |
EA15-24W-630 |
EA15-20W-1230 |
EA15-36W-1230 |
EA15-30W-1530 |
EA15-50W-1530 |
|
|
Size(LxWxH) |
600x70x68mm |
1200x70x68mm |
1500x70x68mm |
||||
|
LF |
300mm |
800mm |
1010mm |
||||
|
LED Type |
SMD2835/3V/150mA/0.5W |
||||||
|
Input Voltage/Frequency |
220V-240V 50Hz/60Hz |
||||||
|
Rated Power ±10% |
15W |
24W |
20W |
36W |
30W |
50W |
|
|
In |
0.08A |
0.13A |
0.11A |
0.2A |
0.167A |
0.278A |
|
|
Power Factor |
>0.9 |
||||||
|
LM ±10% |
1500 |
2500 |
2050 |
3800 |
3100 |
5300 |
|
|
CCT |
2700K-6500K |
||||||
|
CRI(Ra) |
>80 |
||||||
|
Working temperature |
-15℃--- +35℃ |
||||||
|
Environment |
-25℃--- +60℃ |
||||||
|
Lifetime(Hr) |
>30000h |
||||||
|
Q'ty/CTN(PCS) |
12 |
9 |
9 |
||||
|
Innerbox Size(LxWxH) |
607*74*71mm |
1207*74*71mm |
1507*74*71mm |
||||
|
Carton Size(LxWxH) |
618*310*227mm |
1218*235*227mm |
1518*235*227mm |
||||
